specificazione
Elettrico | Voltaggio nominale | 12,8 V. |
Capacità nominale | [email protected] | |
Energia | 3840Wh | |
Resistenza interna | ≤35 mΩ | |
Ciclo di vita | 2000-6000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity | |
Autoscarica | ≤3,5% al mese a 25 ℃ | |
Ricarica standard | Tensione di carica massima | 14,0 ~ 14,6 V. |
Modalità di ricarica | A una temperatura di 0 ℃ ~ 45 ℃, caricata a 14,6 V a una corrente costante di 0,2 ° C, quindi cambiata continuamente con una tensione costante di 14,6 V fino a quando la corrente non è stata superiore a 0,02 ° C | |
Corrente di carica | 100A | |
Corrente di carica max | 100A | |
Scarico standard | Corrente di scarica | 100A |
Max. Corrente continua | 100A | |
Max.Pulse Current | 200A (<3S) | |
Tensione di interruzione di scarica | 10.0 | |
Condizione operativa | Temperatura di carica | Da 0 ℃ a 45 ℃ (da 32 ℉ a 113 ℉) a 60 ± 25% di umidità relativa |
Temperatura di scarico | Da -20 ℃ a 60 ℃ (da -4 ℉ a 140 ℉) a 60 ± 25% di umidità relativa | |
Temperatura di conservazione | Da 0 ℃ a 45 ℃ (da 32 ℉ a 113 ℉) a 60 ± 25% di umidità relativa | |
Resistenza alla polvere d'acqua | IP55 | |
Struttura | Cella e formato | 4S1P, prismatic |
Involucro | Plastica | |
Dimensione (L * W * H * TH) | 522*270*217*217mm | |
Peso | Approx. 27.5Kg | |
terminale | M8 |
Can add LCD fuel gauge.
Can add Control switch.
Can add Coulomb lamp display.
Can add USB connector.
◆ Utilizzando la tecnologia delle celle al litio ferro fosfato, sicurezza superiore, migliaia di cicli, 100% DOD, in condizioni normali.
◆ Protezione automatica incorporata per sovraccarico, sovraccarico, sovracorrente e sovratemperatura.
◆ Esente da manutenzione.
◆ Bilanciamento delle celle interne.
◆ Peso più leggero: circa il 40% ~ 50% del peso di una batteria al piombo comparabile.
◆ Può essere caricato utilizzando la maggior parte delle cariche piombo-acido standard (set).
◆ Intervallo di temperatura più ampio: -20 ℃ ~ 60 ℃.
◆ Supporto per l'espansione delle applicazioni in serie (fino a 51,2 V) e due in parallelo.
La nostra fabbrica
Imballaggio e spedizione
FAQ
Q1. Is it OK to print my LOGO on the product?
R. Sì. Vi preghiamo di informarci formalmente prima della nostra produzione e di confermare il design in primo luogo basato sul nostro campione.
Our factory supports Customized: case, size, battery structure, logo, packaging etc.
Q2. Can I have a sample order?
A.Yes, we welcome sample order to test and check quality.
Low MOQ, 1pc for sample checking is available.
Q3:Which product is hot sale in your company?
A: LiFePO4 battery 24Ah,50Ah,100Ah,200Ah,280Ah,300Ah; 12V,24V, 48V LiFePO4 battery pack and so on.
Q4. What about the lead time?
A. Sample needs 3-7 days, mass production time needs 7-20 days, it depends on order quantity.
Q5. Come procedere con un ordine?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
Q6.Which certificates do you have?
A: Abbiamo CE / FCC / ROHS / UN38.3 / MSDS ... ecc.
Q7.How about warranty?
A:3-5 year warranty
Q8: Are these battery packs compatible with my inverter?
A: Yes, Sir. Our battery pack is compatible with most brands of inverters on the market.
Contact us and let me tell you more.
Q9. How do you ship the goods and how long does it take to arrive?
A.It usually takes 5-7 days to arrive. Train and Airline and Sea(DDP) shipping is also optional.
Q10: How do I know whether you've shipped my order or not?
A: Tracking No. will be offered as soon as your order be shipped out. Before that, our sales will be there to check the packing
status, photo you the done order and let you know the forwarder picked it up.
